Kyaw Stainless, a reputable manufacturer and supplier located in Naypyidaw, Myanmar, specializes in high-quality Stainless Steel 317L Tubing, crafted for exceptional corrosion resistance and durability in tough industrial settings. Our 317L Tubing is made from austenitic stainless steel with a low carbon content, which ensures great weldability and minimizes the risk of sensitization. It boasts impressive strength and toughness, even at high temperatures, making it perfect for applications in chemical processing, marine, and power generation industries. At Kyaw Stainless, we are dedicated to delivering precision-engineered tubing that adheres to international quality standards, guaranteeing long-lasting performance and reliability in harsh and high-temperature environments.
Stainless Steel 317L Tubing is primarily made up of chromium (18–20%), nickel (11–15%), and molybdenum (3–4%), with a low carbon content to avoid carbide precipitation. This alloy has a density of 8.0 g/cm³, a tensile strength of about 515 MPa, and a yield strength of roughly 205 MPa, with an elongation of up to 40%. This distinctive composition boosts its resistance to sulfurous, acetic, and formic acids. Its mechanical strength and non-magnetic properties in the annealed state make it a dependable option for environments that face high corrosion and high temperatures.
| ASTM A213 / ASME SA 213 | Standard Specification for SS TP 317L Seamless Superheater, Condenser, Hydraulic, Boiler and Heat-Exchanger Tubes |
| Shapes | ASME SA213 TP317L Round, Rectangular, Square, Hydraulic, Straight, “U” Shape, Coiled, Honed Tubes, Pan Cake Coils |
| Manufacturing Type | Seamless / ERW / Welded / Fabricated / CDW / CDS / DOM / CEW / 100% X Ray Welded |
| Delivery Condition | Annealed and Pickled (AP), Polished, Bright Annealed (BA), Cold Drawn, MF |
| Surface Finish | BA, 2B, No.4, No.1, No.3, No.8, 8K, HL, 2D, 1D, Mirror Polished, 180G, 320G, 400G Satin/ Hairline, 400G, 500G, 600G or 800G Mirror finish DIN 1.4438 Stainless Steel 317L Tubing or Custom Finish as per customer’s specification |
| Thickness Range | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXH, SCH XXS, SCH XS |
| Standard | SUS, JIS, AISI, ASTM, GB, DIN, EN |
| Relevant Standard | ASTM A213, ASTM A312, ASTM A269, ASTM A778, ASTM A554, ASTM A249, ASTM A269, ASTM A270, ASTM A789, DIN 17456, DIN17457, DIN 17459, JIS G3459, JIS G3463, GOST9941, EN10216, BS3605, GB13296 |
| Value Added Services |
|
| SS 317L | Maximum |
|---|---|
| Ni | 11 – 15 |
| C | 0.035 Maximum |
| Mn | 2 Maximum |
| P | 0.040 Maximum |
| S | 0.03 Maximum |
| Si | 1 Maximum |
| Cr | 18 – 20 |
| Mo | 3 – 4 |
| N | – |
| Element | AISI 317L |
|---|---|
| Density | 8.0 g/cm3 |
| Melting Range | 1454 °C (2650 °F) |
| Tensile Stress | Psi – 75000 , MPa – 515 |
| Yield Stress (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
| Hardness (Brinell) | – |
Contact us to get a quick quote for your requirement.
In industries where durability and high corrosion resistance are critical, stainless steel 317L tubing is widely used. It is frequently used in heat exchangers, power generation systems, pharmaceutical equipment, food and beverage production, marine environments, and chemical and petrochemical processing. Because of its low carbon content, the tubing is perfect for welded structures that are subjected to harsh media. Long service life and low maintenance are guaranteed by its remarkable performance in saline, acidic, and chloride-rich environments. For a variety of industrial and engineering applications throughout Myanmar, Kyaw Stainless offers 317L tubing that can be seamless, welded, or fabricated.
Corrosion-resistant alloy ideal for chemical, pharmaceutical, and food processing industries, offering superior strength, weldability, and durability in harsh environments.
Highly resistant to corrosion, ideal for chemical, pharmaceutical, and food processing industries, offering excellent weldability, strength, and durability in demanding environments.
Excellent resistance to corrosion and high temperatures, making them ideal for use in chemical, petrochemical, and power generation industries with superior heat transfer performance
High corrosion resistance and excellent durability, making it ideal for precise applications in chemical, petrochemical, and pharmaceutical industries, ensuring reliable performance in demanding environments.
Designed for high-temperature and corrosive environments, providing exceptional resistance to oxidation and scaling, making them ideal for industrial boilers and heat exchangers.
High corrosion resistance and durability, ideal for heat exchangers and industrial applications requiring exceptional performance under harsh conditions and high temperatures.
Excellent resistance to corrosion and high temperatures, making them perfect for use in heat exchangers and cooling systems in chemical and petrochemical industries.
Enhance heat transfer efficiency with superior corrosion resistance, making them ideal for applications in heat exchangers, air coolers, and industrial processes requiring reliable performance.
